Products

model

Imported Mercedes-Benz 519 automatic transmission, China VI emission standard, 5.5T

category

BC-680-SD

layout

2025 Model High-Rise Front - Load Right-Handed Drive ( Single Extension)

windows on both sides of the forehead

Passenger capacity

6 people

Interior

system

front of the car

□ White

car

□ Silver □ White

Main board

□ Light-colored wood grain

Color matching door panels

□ Light wood grain + stone grain color

Leather /Fabric

□ White  □ Chocolate​

chassis

parameter

Driver and passenger airbags + side airbags

External dimensions

6850 * 2 548 * 3385mm

Wheelbase: 3665 mm

Transmission: 8AT

Fuel type: diesel

Tire specifications: 2 0 5/75R16 C

12.3-inch floating screen

1 4 V 2 0 0A Smart Generator

+57 V 70 A Second Generator

match

Place

Basic configuration

Body

Exterior

Three Bridges Passenger Door

3.5-meter Holstein manual awning

Dongwu boarding handrail

Dongtai Side Expansion Cabin Rain Shelter

Three Bridges Outside Flat Window

Side expansion compartment

Outdoor lighting

Heshibi manual hatch

Vehicle quick mounting system

Aluminum alloy wheels

Dongtai Level 2 Electric Folding Step

Henghong 2-post electric outrigger

airbag human airbag

Body

structure

Underlying torsional subframe

Double-layer paint-free aluminum plate carriage

XPS structural foam insulation system

One-piece foamed PU insulation layer for forehead

Tow bar

waterway

system

Arena City Pressure Water Supply

REICH grey water piping

LIELE water pipes

Arena gravity water inlet

238-liter in-vehicle fresh water tank

92-liter in-vehicle grey water tank

Hengsheng Ruide external water inlet

Self-priming water inlet

Manual drain valve

LIELE Water Pump System

Wanwei 10L Exchange-Type Hot Water Storage Tank

TRUMA Temperature-Sensitive Automatic Drain Valve

40-mesh water coarse filter

40L Wheeled Mobile Water Tank

Toilet system

Dry and wet separation shower curtain

Thetford C263 Rotary Toilet

RIECH mixing valve

Dingfei Shower Set

ABS+Acrylic vacuum forming countertop sink

Video

furniture

Interior

4D fiber + latex mattress

Four-way movable height-adjustable table

Pull-out bed

Felingel PU Keel

LAMILUX Double Layer Flooring

Fabric curtains

Air conditioning exhaust system

Yaoyue 4KW Highland Edition Diesel Air Heater Unit

Yaoyue 12KW Highland Edition Diesel Water Heating Unit

TRUMA Heating Piping System

KME 3000W Car Split Air Conditioner

Sanqiao 10-speed electric rainproof ventilation fan

Forced exhaust vent

kitchen

system

Chengbang range hood

Mobo washing machine

Thetford T2156 refrigerator

Xiaomi direct drinking water faucet

Guangrun sink

Dingfei hot and cold water faucet

energy

system

5-key simplified control panel

Topway 48V Control System

Arena external AC charging port

Indoor AC 110V output socket

Yichu 1200W Rigid Solar Panel

Arena external power supply port

12V USB charging port

Topband 48V 420AH battery pack, 20 kWh

48V 4800W Inverter/Charger All-in-One Machine

Varta 45 AH relay battery

Parking

Safety

Zhuonuo 4-way parking monitoring

Senheman CO/Smoke/Liquefied Gas Alarm

fire extinguisher

Zhuonuo Streaming Rearview Mirror

accompanying vehicle

Accessories

110V slow charging gun

15-meter external AC power cord

Product Instruction Manual

Fuse kit

16-meter water pipe storage rack set

illustrate

Note: If the selected optional accessories conflict with the basic configuration , the optional accessories will prevail and will cover the corresponding basic configuration without further notice.
